Angle iron is a versatile and commonly used structural steel shape that is often used in construction and manufacturing. It is named for its L-shaped cross-section, with equal or unequal legs. Angle iron is known for its strength and durability, making it a popular choice for various applications.
One important consideration when using angle iron is its weight capacity. The weight capacity of angle iron can vary depending on its dimensions and material composition. To help you determine the weight capacity of angle iron, refer to the angle iron weight capacity chart below.
Angle Iron Weight Capacity Chart
Angle Iron Weight Capacity Chart
Below is a general angle iron weight capacity chart that provides an estimate of the weight capacity for various sizes of angle iron. Please note that actual weight capacities may vary depending on the specific grade of steel and other factors. Use this chart as a guideline when selecting angle iron for your project:
| Size (inches) | Weight Capacity (lbs/ft) |
|---|---|
| 1/2 x 1/2 x 1/8 | 0.38 |
| 3/4 x 3/4 x 1/8 | 0.59 |
| 1 x 1 x 1/8 | 0.76 |
| 1 x 1 x 3/16 | 1.12 |
Conclusion
When using angle iron for your project, it is important to consider the weight capacity to ensure the structural integrity and safety of your design. Refer to the angle iron weight capacity chart provided above as a guideline, and consult with a structural engineer if needed to determine the appropriate size and grade of angle iron for your specific application.
By understanding the weight capacity of angle iron, you can make informed decisions when selecting materials for your project and ensure that it meets the necessary strength requirements.
